Short Lead Time for China E-Light

Short Description:


Product Detail

Our organization puts emphasis to the administration, the introduction of talented personnel, and also the construction of team building, making an attempt hard to enhance the standard and liability consciousness of workers members. Our business successfully attained IS9001 Certification and European CE Certification of Short Lead Time for China E-Light, Trust us and you’ll gain far more. Be sure to really feel free of charge to contact us for additional details, we assure you of our best attention at all times.
Our organization puts emphasis to the administration, the introduction of talented personnel, and also the construction of team building, making an attempt hard to enhance the standard and liability consciousness of workers members. Our business successfully attained IS9001 Certification and European CE Certification of China E-Light, E-Light Beauty Device, Relying on superior quality and excellent post-sales, our products sell well in America, Europe, the Middle East and South Africa. We are also the appointed OEM factory for several worlds’ famous products brands. Welcome to contact us for further negotiation and cooperation.

Overview
Quick Details
Place of Origin:
Germany
Brand Name:
LaserTell
Model Number:
NL
IPL+ RF:
yes
After-sales Service Provided:
Online support
Type:
IPL
Certification:
CE ISO
Feature:
Acne Treatment, Anti-Puffiness, Blood Vessels Removal, Breast Enhancers, Dark Circles, Face Lift, Hair Removal, Pigment Removal, Pigmentation Correctors, Pore Remover, Skin Rejuvenation, Skin Tightening, Wrinkle Remover
Application:
For Commercial
Warranty:
2 Years
Keyword:
ipl lamp
Wavelength:
400-950nm
Product name:
IPL Xenon Lamp
Product Certification certification
CE Certified.
Valid from 2016-03-31 until 2021-03-30
Supply Ability
500 Set/Sets per Month

Packaging & Delivery
Packaging Details
Aluminum Packing Box with EPE Foam
Port
Beijing

Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 – 10 >10
Est. Time(days) 3 To be negotiated

Product Description

Advantages:


1) Design consultancy with our product experts.

2) Customized prototype design and quotation. completed within 5 days

3) Lamp to lamp consistency.
4) High standards of manufacturing.
5) Long lifetime (300,000~1 million shots)
6) Patented cathode design.
Parameter


Dimension parameters


Lamp's bore (ID)=5mm
Lamp's Outside dia.(OD) =7mm
Lamp's Arc length (AL) =60±1.5mm
Lamp's Body length(BL) =120±2mm
O-ring centre (OC) =104mm
Pole dia. (PD) =2mm
Overall length (OAL)=480mm
wire length (WL) = 180mm


Technical Parameters


maximum average power=1,886W
maximum peak current =800A
operating voltage = 1,750V(max)
operating voltage =500V(min)
minimum trigger voltage =16KV
minimum trigger pulse=0.6μs
impedance constant= 15.84 Ko(Ω.A)
explosion energy constant = 73,680 (W./S)

Before & After
Detailed Images
Certifications
Packing & Delivery
Packaging
Packaging
Aluminium Package
Delivery
Within 5 Working Days



Packaging Details
The normal package is Aluminium Box with EPE Foam.
If export to remote countries, the wooden box will be added as well.
 All parts packaged available according to customers special request.
LASERTELL
Our Service

Pre-Sales Service


* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service


* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.

* 24 hours + 7 days after-sale service and technical supports

* Lifelong Service (no matter 3 years or 5 years, or more…)

Our organization puts emphasis to the administration, the introduction of talented personnel, and also the construction of team building, making an attempt hard to enhance the standard and liability consciousness of workers members. Our business successfully attained IS9001 Certification and European CE Certification of Short Lead Time for China E-Light, Trust us and you’ll gain far more. Be sure to really feel free of charge to contact us for additional details, we assure you of our best attention at all times.
Short Lead Time for China E-Light, E-Light Beauty Device, Relying on superior quality and excellent post-sales, our products sell well in America, Europe, the Middle East and South Africa. We are also the appointed OEM factory for several worlds’ famous products brands. Welcome to contact us for further negotiation and cooperation.
